Manual Hydraulic Lift Jack 800kg – Cost-Effective Mobile Lifting Platform

A practical lifting solution for workshops that need reliable vertical positioning without batteries or electrical components. This manual hydraulic lift jack delivers stable lifting performance with low operating cost and minimal maintenance.

Built for Everyday Workshop Tasks

Ideal for handling gearboxes, medium-weight components, and parts loading operations. The foot-operated hydraulic system allows controlled lifting, while the smooth release valve ensures precise lowering during installation work.

Why Choose the Manual Version

• No battery, no wiring, no charging required
• Lower purchase and maintenance cost
• Full control over lifting speed via foot pedal
• Hydraulic lowering for accurate positioning
• Mobile design for easy movement between work areas

Workshop Applications

• Transmission handling (light to medium duty)
• Component lifting to working height
• Material loading and unloading
• Mobile adjustable work platform

Compact and Easy to Maneuver

The reinforced steel platform and PU wheels allow smooth transport across workshop floors, while the ergonomic handle provides better control during positioning.

Key Specifications

• Capacity: 800 kg
• Max lifting height: 1500 mm
• Lowered height: 500 mm
• Platform size: 1200 × 600 mm
• Table thickness: 80 mm
• Overall length: 1320 mm
• Overall width: 610 mm
• Handle height: 980 mm
• Wheel diameter: 125 mm PU
• Lifting speed: approx. 12 mm per pedal stroke
• Net weight: 150 kg
• Color: Yellow / Orange

The Advantage

Same working height as electric models, but with a simpler, more economical system. Perfect for workshops that need a dependable lifting platform without electrical components.
